Feature
Specification
| Model | 230 |
|---|---|
| Power supply | 110-240VAC can be used |
| Frequency | 50-60Hz |
| Maximum output | 60W |
| Power consumption | 1.0A/230VAC，1.8A/115VAC |
| Fuse | 2.5A |
| Temperature setting Blood | 37℃ |
| Temperature setting Infusion | 40℃ |
| Temperature setting Other | Others 41°C (in units of 1°C, can be adjusted arbitrarily from 30°C to 45°C) |
| Control precision | ±2℃ |
| Over temperature protection | When set at 37°C, 41°C±1°C and physical formula 85°C±3°C |
| Over Current Protection | 2A |
| Ambient temperature | Operation +10℃~+40℃, storage/transportation -20℃~70℃ |
| Relative humidity | Operation 30-75%, storage/transportation 30-90% |
| Operation type | Continuous operation |
| Alarm function | When the temperature exceeds the set temperature by 1°C, an alarm will be generated, and the alarm will continue until the over-temperature situation is resolved. Alarm type sound alarm visual alarm |
| Size Controller | 246x150x74mm |
| Size Hose | L 1500mm D 5±1mm |
| Weight N.W | 1.27 Kgs |
